Maeda Mini Crawler Cranes
maeda mini crawler cranes

MK-1033C


Lifting Capacity : 0.995t ×1.0m
Maximum Working Radius : 9.65m
Dimensions (L×W×H) : 2710×750×1970mm
Multi Outrigger Positions
Multi Joystick Remote Controller

Technical specifications and working range




MC-174C


Lifting Capacity : 1.72t×1.0m
Maximum Working Radius : 5.17m×0.22t
Slim Body: 590mm

Technical specifications and working range
MC-104C photo2


MC-285C


Lifting Capacity : 2.82t×1.4m
Maximum Working Radius : 8.205m×0.15t
Dimensions (L×W×H) : 2715×750×1440mm

Technical specifications and working range
MC-285C photo1


MC-305C-2


Lifting Capacity : 2.98t×2.5m
Maximum Working Radius :12.16m×0.26t
Dimensions (L×W×H) : 4285×1280×1695mm
Outrigger Safety System
4 Fall/2 Fall Hook Block
Two Way Remote Controller

Technical specifications and working range
MC-305C-2 photo1


MC-405C


Pick & Carry Duties
Lifting Capacity : 3.83t×2.7m (3.03 ton×3.5 m)
Maximum Working Radius :16m×0.21t
Dimensions (L×W×H) : 4980×1380×1980mm
Outrigger Safety System
4 Fall/2 Fall Hook Block
Two Way Remote Controller

Technical specifications and working range
MC-405C photo1



MC-815C


Crane capacity 8.09t x 2.4m
Max. lifting height 19.6m
Max. working radius 18.8m x 0.34t
Max. lifting height (underground) -21m (6 falls)

Technical specifications and working range
MC-405C photo1



CC423S-1


Crane capacity 2.93t x 1.5m
Max. lifting height 9.46m
Max. working radius 8.38m x 0.2t
Max. lifting height (underground) -15.5m (4 falls)

Technical specifications and working range
LC785M-6 photo1



CC985S-1


Crane capacity 4.9t x 2.1m
Max. lifting height 16.5m
Max. working radius 14.67m x 0.2t
Max. lifting height (underground) -25m (4 falls)

Technical specifications and working range
LC785M-6 photo2



CC1485S01


Crane capacity 6t x 2.6m
Max. lifting height 16.7m
Max. working radius 16.1m x 0.43t
Max. lifting height (underground) -24.5m (4 falls)

Technical specifications and working range
LC785M-6 photo1
